Matrix Mono
Inventor Matrix Mono Engineering Data Book
Matrix Mono
74
Inventor Matrix Mono Engineering Data Book
Table 3-4.1: Wiring requirements
Item Description AC/DC Required number of conductors Maximum running current
1 Solar energy kit signal cable AC 2 200mA
2 User interface cable AC 5 200mA
3 Room thermostat cable AC 2 or 3 200mA(a)
4 Boiler control cable / 2 200mA
5 Thermistor cable for T1B DC 2 (b)
9 DHW pump control cable AC 2 200mA(a)
10 3-way valve control cable AC 2 200mA(a)
11 3-way valve control cable AC 2 or 3 200mAC
12 Thermistor cable DC 2 (b)
13 Booster heater control cable AC 2 200mA(a)
15 Power supply cable for unit AC
2+GND(1-Phase)
3+GND(3-Phase)
31A (1-Phase)
15A (3-Phase)
16 Power supply cable for backup heater AC
2+GND(1-Phase)
3+GND(3-Phase)
14A (1-Phase)
6A (3-Phase)
