INVENTOR L4VI32-09 Service Manual

Installation and Maintenance
73
Service Manual
127
Installation and Maintenance
Service Manual
Procedure
Step
Screws
Screws
Screws
Screws
Screw off the screws that are locking the front
cover. Then take it off.
Front cover
4. Remove the front cover
5. Remove axial ow blade
Remove the nut xing axial ow blade and
then remove the axial ow blade.
Nut
Axial ow blade
128
Installation and Maintenance
Service Manual
Right side plate
Electric box
assy
Remove the screws 2 fixing right side
plate and then remove the right side plate.
Screws 2
Right side plate
Protective
grille
Screws 1
Screws 2
Remove the screws 1 fixing protective
grille and then remove the protective
grille.
Remove the screws xing electric box
assy ; pull out each wiring terminal; lift the
electric box assy upwards to remove it.
Note:
When pulling out the wiring terminal, pay
attention to loose the clasp and dont pull
it so hard.
6. Remove protective grille and right side plate
7. Remove electric box assy
ProcedureStep
