4
2 Introduction
2.1 Basic features
The inverter is a high-quality inverter which can convert solar energy to AC energy and store
energy into battery. The inverter can be used to optimize self consumption, store in the
battery for future use or feed-in to public grid. Work mode depends on PV energy and
user’s preference. It can provide power for emergency use during the grid lost by using the
energy from battery and inverter (generated from PV).
2.2 System Diagram
2.2.1 Networking application
Ma in Breaker
On Grid Breaker
Off Grid Breaker
To Next Page
