7
2.4 Dimension
2.5 Port Description
Object
Description
A
DC switch
B
PV1~PV4 input
C
Wifi/GPRS
D
BAT input
E
BACK-UP output
F
GRID
G
DRM/BMS/CT
K
DRY IO/CAN/USB
