INVT BD-RH1 Series User Manual

9
Protection
Grounding detection
YES
Island Protection
YES
Battery reverse Polarity
YES
Insulation Resistor
Detection
YES
Residual Current
Monitoring Unit
YES
Output Over Current
Protection
YES
Back-up Output Short
Protection
YES
Terminal temperature
detection
YES
Output Over Voltage
Protection
YES
Output Under Voltage
Protection
YES
General Data
Operating Temperature
Range
-25 ~ +60°C
Relative Humidity
0-95%
Operating Altitude
0~4000m
Ingress Protection
IP65/NEMA 3R
Weight
32kg
Size
(Width*Height*Depth）
530mm x 565mm x 220mm
Cooling
Natural Convection
Noise emission
<25dB
<29dB
<29dB
<29dB
<29dB
Display
LCD
Communica tio n With
BMS/Meter
/EMS
Modbus, RS485，WIFI,4G
4 Installation
4.1 Check for Physical Damage
