INVT BD-RH1 Series User Manual

8
3 Technical Parameters
Technical Data
BD6KTL-
RH1
BD7K6TL-
RH1
BD9KTL-
RH1
BD10KTL-
RH1
BD11K4TL-
RH1
Efficiency
Europe Efficiency
>=98.2%
MAX. Battery to Load
Efficiency
>=97.2%
AC Output Data(On-Grid)
MAX. Apparent Power
Output to Grid
6kVA
7.6kVA
9kVA
10kVA
11.4KVA
Output Voltage Range
175V-270V /230 1 phase
Output Frequency
50/60Hz（45 to 54.9Hz / 55 to 65Hz）
Max. AC Current Output
to Grid
26A
33A
39.2A
43.5A
49.5A
Output Power Factor
0.8leading…0.8lagging
Output THDI
< 2%
AC Output Data(Back-Up)
Nominal. Apparent
Power Output
6kVA
7.6kVA
9kVA
10KVA
11.4KVA
Nominal Output
Voltage
220V~240V
Nominal Output
Frequency
50Hz/60Hz
Output THDU
< 2%
PV Sting Input
MAX. DC Input Power
8.5kW
10kW
11.7kW
13kW
14.82kW
NO. MPPT Tracker
4
MPPT Range
150 - 500V
MAX. DC Input Voltage
500V
MAX. Input Current
12A
12A
12A
12A
12A
Battery Input Data
MAX.
Charging/Discharging
Current
80 A / 80 A
80 A / 80 A
62.5A/62.5
A
69.5A/69.5A
79A/79A
Battery Voltage Range
96V~350V
90V~350V
150V~350V
150V~350V
150V~350V
Battery Type
LI-ion/Lead-acid
Charging Strategy for
Li-Ion Battery
Self-adaption to BMS

INVT BD-RH1 Series Specifications

General

Brand	INVT
Model	BD-RH1 Series
Category	Inverter
Language	English
