Technical Data
4.4 Efficiency, Safety and Protection (apply to version E, I)
Model
BD3KTL-RL1
BD4KTL-R L1
BD5KTL-R L1
BD3K6TL-RL1
BD4K6TL-RL1
BD6KTL-R L1
MPPT
efficiency
99.9%
99.9% 99.9%
Euro
efficiency
97%
97% 97%
Max.
efficiency
97.6%
97.6% 97.6%
Max.
Battery charge efficiency
95% 95% 95%
Max.
Battery discharge efficiency
95% 95% 95%
Safety
& Protection
Over/under voltage
protection
YES
DC
isolation protection
YES
Monitoring
ground fault
protection
YES
Grid
protection
YES
DC
injection monitoring
YES
Back
feed current monitoring
YES
Residual
current detection
YES
Anti
-islanding protection
YES
Over
load protection
YES
Over
heat protection
YES
Technical Data
4.3 Internal Charger (apply to version E,I)
Model
BD3KTL-
RL1
BD3K6TL-
RL1
BD4KTL-
RL1
BD4K6TL-
RL1
BD5KTL
-
RL1
BD6KTL-
RL1
Battery
type
Lithium battery
Battery
voltage range[V]
42-59
Recommended
battery voltage[V]
48
Max.
charge/discharge current[A]
95/62.5
95/76.6
95/83.
3
95/95.8
95/110 95/110
Peak
charge/discharge current[A]
95/62.5
95/76.6
95/83.
3
95/95.8
95/110
95/110
Communication
interfaces
CAN/RS485/WIfI/LAN/DRM
Reverse
connect protection
Yes
4.5 EPS output (apply to version E , I)
Model
BD3KTL-R L 1 BD4KTL-R L1 BD5KTL-
RL1
BD3K6TL-RL1
BD4K6TL-RL1
BD6KTL-
RL1
EPS
rated power[VA]
3000/3600 4000/4600 5000/6000
Max.
EPS power[VA]
3000/3600 4000/4600 5000/6000
EPS
rated voltage, Frequency
230VAC, 50/60Hz
EPS
rated current[A]
13/16 17.4/20 21.7/26
Max.
EPS current[A]
13/16 17.4/20 21.7/26
Switch
time[s]
<500ms
Total
harmonic distortion(THDv
)
<2%
Parallel
operation
Yes
Compatible
with the generator
Yes(signal provided only)
16 17
Model
BD3KTL-
RL1
BD4KTL-
RL1
BD5KTL-R L 1
BD3K6TL-
RL1
BD4K6TL-
RL1
BD6KTL-R L 1
Dimension
[W/H/D](mm)
550*520*200
Dimension
of packing [W/H/D](mm
)
665*635*330
Net
weight [kg]
25 25 25
Gross
weight [kg]
31 31 31
Installation
Wall-mounted
Operating temperature
range[℃]
-25~+60 (derating at 45)
Storage
temperature [℃]
-25~+60
Storage/Operation relative
humidity
4%~100% (Condensing)
Altitude
[m]
<2000
Ingress
Protection
IP65(for outdoor use)
Protective
Class
Ⅰ
Night
-time consumption
<3W
Over
Voltage Category
Ⅱ(MAINS),Ⅱ( PV, Battery)
Pollution
Degree
II
cooling
Nautral
Noise
level
＜40dB
Inverter
Topology
non-isolated
Communication
interface
CAN/RS485/WIfI/LAN/DRM
