Communication Protocol
110
The data address of control and status parameters please refer to the following table.
Parameter
Description
Address Meaning of value
R/W
Feature
0001H: Forward
0002H: Reverse
0003H: JOG forward
0004H: JOG reverse
0005H: Stop
0006H: Coast to stop
0007H: Reset fault
Control
command
1000H
0008H: JOG stop
W/R
0001H: Forward running
0002H: Reverse running
0003H: Standby
Inverter status 1001H
0004H: Fault
R
Communication
setting
2000H
Communication Setting Range
(-10000~10000)
Note: the communication setting is the
percentage of the relative value
(-100.00%~100.00%). If it is set as
frequency source, the value is the
percentage of the maximum frequency
(P0.04). If it is set as PID (preset value
or feedback value), the value is the
percentage of the PID.
W/R
3000H Output frequency R
3001H Reference frequency R
3002H DC Bus voltage R
3003H Output voltage R
3004H Output current R
3005H Rotation speed R
3006H Output power R
3007H Output torque R
3008H PID preset value R
3009H PID feedback value R
300AH Input terminal status R
300BH Output terminal status. R
300CH Input of AI1 R
300DH Input of AI2 R
300EH Reserved R
300FH Reserved R
3010H HDI frequency R
3011H Reserved R
Status
parameters
3012H Step No. of PLC or multi-step R
