Wiring
19
.4.4 Specifications of Breaker, Cable, Contactor and Reactor
4.4.1 Specifications of breaker, cable and contactor
Model No.
Circuit Breaker
(A)
Input/Output
Cable (mm
2
)
AC Contactor
(A)
1AC 220V ±15%
CHE100-0R4G-S2 16 2.5 10
CHE100-0R7G-S2 16 2.5 10
CHE100-1R5G-S2 20 4 16
CHE100-2R2G-S2 32 6 20
3
3
A
A
C
C
2
2
2
2
0
0
V
V
±
±
1
1
5
5
%
%
CHE100-0R4G-2 16 2.5 10
CHE100-0R7G-2 16 2.5 10
CHE100-1R5G-2 20 4 16
CHE100-2R2G-2 32 6 20
CHE100-004G-2 40 6 25
CHE100-5R5G-2 63 6 32
CHE100-7R5G-2 100 10 63
CHE100-011G-2 125 25 95
CHE100-015G-2 160 25 120
CHE100-018G-2 160 25 120
CHE100-022G-2 200 35 170
CHE100-030G-2 200 35 170
CHE100-037G-2 200 35 170
CHE100-045G-2 250 70 230
