INVT CHE100-0R7G-S2 User Manual

Wiring
22
4.4.3 Specification of braking unit and braking resistor
Braking unit
Braking resistor
(100% braking torque) Model No.
Order No. Quantity Specification Quantity
3AC 220V ±15%
CHE100-0R4G-2
275Ω/75W 1
CHE100-0R7G-2
275Ω/75W 1
CHE100-1R5G-2
138Ω/150W 1
CHE100-2R2G-2
91Ω/220W 1
CHE100-004G-2
52Ω/400W 1
CHE100-5R5G-2
37.5Ω/550W 1
CHE100-7R5G-2
Built-in 1
27.5Ω/750W 1
CHE100-011G-2
1 19Ω/1100W 1
CHE100-015G-2
1 13.6Ω/1500W 1
CHE100-018G-2
1 12Ω/1800W 1
CHE100-022G-2
1 9Ω/2200W 1
CHE100-030G-2
DBU-055-2
1 6.8Ω/3000W 1
CHE100-037G-2
2 11Ω/2000W 2
CHE100-045G-2
DBU-055-2
2 9Ω/2400W 2
3AC 380V ±15%
CHE100-0R7G-4 900Ω/75W 1
CHE100-1R5G-4 460Ω/150W 1
CHE100-2R2G-4 315Ω/220W 1
CHE100-004G/5R5P-4 175Ω/400W 1
CHE100-5R5G/7R5P-4 120Ω/550W 1
CHE100-7R5G/011P-4 100Ω/750W 1
CHE100-011G/015P-4 70Ω/1100W 1
CHE100-015G/018P-4
Built-in 1
47Ω/1500W 1
CHE100-018G/022P-4
38Ω/2000W 1
CHE100-022G/030P-4
32Ω/2200W 1
CHE100-030G/037P-4
23Ω/3000W 1
CHE100-037G/045P-4
DBU-055-4 1
19Ω/3700W 1
