Communication Protocol
115
10.7.2 ASCII mode, read 2 data from 0004H:
The request command is:
START ‘:’
‘0’
Node address
‘1’
‘0’
Command
‘3’
‘0’
High byte of start address
‘0’
‘0’
Low byte of start address
‘4’
‘0’
High byte of data number
‘0’
‘0’
Low byte of data number
‘2’
LRC CHK Hi ‘F’
LRC CHK Lo ‘6’
END Lo CR
END Hi LF
The reply is
START ‘:’
‘0’
Node address
‘1’
‘0’
Command
‘3’
‘0’
Returned byte number
‘4’
‘0’
Higher byte of 0004H
‘0’
‘0’
Low byte of 0004H
‘0’
‘0’
High byte of 0005H
‘0’
‘0’
Low byte of 0005H
‘0’
LRC CHK Lo ‘F’
LRC CHK Hi ‘8’
END Lo CR
END Hi LF
