INVT CHE100-0R7G-S2 User Manual

Detailed Function Description
53
10
DOWN
command
11
Clear
UP/DOWN
Use this terminal to clear UP/DOWN setting. Please refer to
description of P0.02.
12
Multi-step
speed
reference1
13
Multi-step
speed referenc
e
2
14
Multi-step
speed
reference 3
8 steps speed control can be realized by the combination of
these four terminals. For details, please refer to: Multi-step
speed reference terminal status and according step value
table:
15
ACC/DEC
time selection
2 groups of ACC/DEC time can be selected by the
combination of these two terminals.
Terminal ACC/DEC time
Corresponding
Parameter
OFF
Acceleration Time
0
P0.08、P0.09
ON
Acceleration Time
1
P8.00、P8.01
16 Pause PID
PID adjustment will be paused and inverter keeps output
frequency unchanged.
17
Pause
traverse
operation
Inverter keeps output frequency unchanged. If this terminal
is disabled, inverter will continue traverse operation from
current frequency.
18
Reset
traverse
operation
Reference frequency of inverter will be forced as center
frequency of traverse operation.
19
ACC/DEC
ramp hold
Pauses acceleration or deceleration and maintains output
frequency. When this terminal is disabled,
acceleration/deceleration is restarted.
