INVT CHE100-0R7G-S2 User Manual

Detailed Function Description
58
3 Fault output ON: Inverter is in fault status.
4 FDT reached Please refer to description of P8.13 and P8.14.
5
Frequency
reached
Please refer to description of P8.15.
6
Zero speed
running
ON: The running frequency of inverter is zero.
7
Upper frequency
limit reached
ON: Running frequency reaches the value of P0.05.
8
Lower frequency
limit reached
ON: Running frequency reaches the value of P0.06.
9~10 Reserved Reserved
Function
Code
Name Description
Setting
Range
Factory
Setting
P6.02 AO selection
Multifunctional analog
output
0~10 0
Current (0~20mA) or voltage (0~10V) output can be selected by Jumper J15.
AO functions are indicated in the following table:
Setting
Value
Function Range
0 Running frequency 0~maximum frequency (P0.04)
1 Reference frequency 0~ maximum frequency (P0.04)
2 Motor speed 0~2* rated synchronous speed of motor
3 Output current 0~2* inverter rated current
4 Output voltage 0~1.5* inverter rated voltage
5 Output power 0~2* rated power
6 Output torque 0~2*rated current
7 AI1 voltage 0~10V
8 AI2 voltage/current 0~10V/0~20mA
9~10 Reserved Reserved
Function
Code
Name Description
Setting
Range
Factory
Setting
P6.03 AO lower limit 0.0%~100.0% 0.0~100.0 0.0%
P6.04
AO lower limit
corresponding output
0.00V ~10.00V 0.00~10.00 0.00V
