INVT GD100-2R2G-SS2-PV User Manual

Goodrive100-PV Series Solar Pumping VFD Function parameters
56
Function
code
Name
Detailed illustration of parameters
Default
Modify
min. reference
voltage
reference during maximum power
tracking. It equals the solar cell panel
open-circuit voltage multiplied P15.26.
P18.04
Current inductive
current
It is transferred from the boost module.
This function code is valid only in AC
mode and invalid in PV mode.
●
P18.07
PV input power
Reserved. Unit: kW
●
P18.08
Previous PV input
power
Reserved
●
P18.09
Previous PV
voltage
Reserved
●
P18.10
Device
configuration
display
0x00–0x11
Ones on LED
0: PV power supply
1: AC grid power supply
Tens on LED
0: Detection indicates the system
contains the boost module.
1: Detection indicates the system does
not contain the boost module.
●
P18.11
Current pump flow
Unit: cubic meter/hour
0.0
●
P18.12
Current pump lift
Unit: meter
0.0
●
P18.13
MSBs in total
pump flow
This function code displays the 16 most
significant bits (MSBs) in the total pump
flow. Unit: cubic meter
0
●
P18.14
LSBs in total pump
flow
This function code displays the 16 least
significant bits (LSBs) in the total pump
flow. Unit: cubic meter. Total pump flow
= P18.13*65535 + P18.14
0.0
●
