INVT GD170-045-4-PV User Manual

Goodrive170-PV Series Solar Pump Inverter Options
-59-
For details, see the GPRS/GPS Adaptor Operation Manual which comes with the GPRS
module or contact the local INVT office. Provide the model and serial number of the
product you query about.
A.3 Cable
A.3.1 Powe cable
The sizes of the input power cables and motor cables must comply with local regulations.
Note: If the electrical conductivity of the motor cable shield layer does not meet the
requirements, a separate PE conductor must be used.
A.3.2 Control cable
A relay cable needs to carry the metal braided shield layer.
Keypads need to be connected by using network cables. In complicated electromagnetic
environments, shielded network cables are recommended.
A shielded twisted-pair cable is recommended for a communication cable.
Note:
 Analog signals and digital signals cannot share a same cable, and their cables must
be routed separately.
 Before connecting the input power cable of the inverter, check the insulation
conditions of the cable according to local regulations.
Recommended power cable sizes for standard inverter models:
Inverter model
Recommended cable size
(mm
2
)
Terminal
screw
Tightening
torque (Nm)
(+)/(-), R/S/T, U/V/W
PE
GD170-2R2-4-PV
1.5
1.5
M4
0.8
GD170-004-4-PV
2.5
2.5
M4
1.2–1.5
GD170-5R5-4-PV
2.5
2.5
M4
1.2–1.5
GD170-7R5-4-PV
4
4
M5
2–2.5
GD170-011-4-PV
6
6
M5
2–2.5
GD170-015-4-PV
10
10
M5
2–2.5
GD170-018-4-PV
16
16
M5
2–2.5
GD170-022-4-PV
25
16
M5
2–2.5
GD170-030-4-PV
25
16
M6
4–6
GD170-037-4-PV
35
16
M6
4–6
GD170-045-4-PV
35
16
M8
10
