Goodrive350 series high-performance multi-function inverter Chapter 6
-135-
Function
code
Name
Detailed parameter description
Default
value
Modi
fy
above)
11: Set via EtherCat/Profinet communication
12: Set via PLC
P03.12
Torque set by
keypad
-300.0%300.0% (rated motor current)
20.0%
P03.13
Torque reference
filter time
0.00010.000s
0.010s
P03.14
Source of upper
limit frequency
setup of forward
rotation in torque
control
0: Keypad (P03.16)
1: AI1 (100% corresponds to max. frequency)
2: AI2 (the same as above)
3: AI3 (the same as above)
4: Pulse frequency HDIA (the same as above)
5: Multi-step (the same as above)
6: MODBUS communication (the same as above)
7: PROFIBUS /CANopen/ DeviceNet communication
(the same as above)
8: Ethernet communication (the same as above)
9: Pulse frequency HDIB (the same as above)
10: EtherCat/Profinet communication
11: PLC
12: Reserved
0
P03.15
Source of upper
limit frequency
setup of reverse
rotation in torque
control
0: Keypad (P03.17)
1: AI1 (100% corresponds to max. frequency)
2: AI2 (the same as above)
3: AI3 (the same as above)
4: Pulse frequency HDIA (the same as above)
5: Multi-step (the same as above)
6: MODBUS communication (the same as above)
7: PROFIBUS /CANopen/ DeviceNet communication
(the same as above)
8: Ethernet communication (the same as above)
9: Pulse frequency HDIB (the same as above)
10: EtherCat/Profinet communication
11: PLC
12: Reserved
Note: Source 1-11, 100% relative to the max.
frequency
0
P03.16
Keypad limit
value of upper
This function code is used to set frequency limit.
100% corresponds to the max. frequency. P03.16
50.00Hz
