INVT GD350-1R5G-4

Goodrive350 series high-performance multi-function inverter Chapter 6
-136-
Function
code
Name
Detailed parameter description
Default
value
Modi
fy
limit frequency of
forward rotation
in torque control
sets the value when P03.14=1; P03.17 sets the
value when P03.15=1.
Setting range: 0.00Hz–P00.03 (max. output
frequency)
P03.17
Max. output
frequency
50.00Hz
○
P03.18
Source of upper
limit setup of the
torque during
motoring
0: Keypad (P03.20)
1: AI1 (100% relative to three times of motor current)
2: AI2 (the same as above)
3: AI3 (the same as above)
4: Pulse frequency HDIA (the same as above)
5: MODBUS communication (the same as above)
6: PROFIBUS/CANopen/DeviceNet communication
(the same as above)
7: Ethernet communication (the same as above)
8: Pulse frequency HDIB (the same as above)
9: EtherCat/Profinet communication
10: PLC
11: Reserved
0
○
P03.19
Source of upper
limit setup of
brake torque
0: Keypad (P03.21)
1: AI1 (100% relative to three times of motor current)
2: AI2 (the same as above)
3: AI3 (the same as above)
4: Pulse frequency HDIA (the same as above)
5: MODBUS communication (the same as above)
6: PROFIBUS/CANopen/DeviceNet communication
(the same as above)
7: Ethernet communication (the same as above)
8: Pulse frequency HDIB (the same as above)
9: EtherCat/Profinet communication
10: PLC
11: Reserved
0
○
P03.20
Set upper limit of
the torque when
motoring via
keypad
This function code is used to set torque limit.
Setting range: 0.0–300.0% (rated motor current)
180.0%
○
P03.21
Set upper limit of
brake torque via
keypad
180.0%
○
P03.22
Flux-weakening
Used when asynchronous motor is in flux-weakening
0.3
○
