Goodrive350 series high-performance multi-function inverter  Chapter 6
-141-
Detailed parameter description
voltage of motor 1)
Setting range of P04.07: P04.05–P02.02 (rated
frequency of motor 1) or P04.05– P02.16 (rated
frequency of motor 1)
Setting range of P04.08: 0.0%–110.0% (rated
voltage of motor 1)
V/F slip
compensation
gain of motor 1
This  function  code  is  used  to  compensate  for  the
motor speed changes occurred during load variation
in SVPWM control mode, thus improving the rigidity
of  mechanical  characteristics  of  motor.  Rated  slip
frequency of the motor should be calculated.
△f=fb-n×p/60
of which: fb is rated motor frequency, corresponds to
P02.02;  n  is  rated  motor  speed,  corresponds  to
P02.03; p is the number of motor pole pairs. 100%
corresponds to the rated slip frequency of motor  △f.
Setting range: 0.0–200.0%
Low-frequency
oscillation control
factor of motor 1
Under SVPWM control mode, the motor, especially
the large-power motor may experience current
oscillation during certain frequencies, which may
lead to unstable motor operation, or even inverter
overcurrent, users can adjust these two parameters
properly to eliminate such phenomenon.
Setting range of P04.10: 0–100
Setting range of P04.11: 0–100
Setting range of P04.12: 0.00Hz–P00.03 (max.
output frequency)
High-frequency
oscillation control
factor of motor 1
Oscillation
control threshold
of motor 1
V/F curve setup
of motor 2
0: Straight V/F curve;
1: Multi-point V/F curve
2: Torque-down V/F curve (1.3
th
 order)
3: Torque-down V/F curve (1.7
th
 order)
4: Torque-down V/F curve (2.0
nd
 order)
5: Customize V/F (V/F separation)
0.0%: (automatic) 0.1%–10.0%
Motor 2 torque
boost cut-off
0.0%–50.0% (relative to rated frequency of motor 2)
V/F frequency
point 1 of motor 2
