INVT Goodrive350-19 Series User Manual

Goodrive350-19 series VFD Operating
- 186 -
Function
code
Name
Description
Default
value
P10.23
Running time of 10
th
step
0.0–6553.5s (min)
0.0s
P10.24
Multi-step speed 11
-100.0–100.0%
0.0%
P10.25
Running time of 11
th
step
0.0–6553.5s (min)
0.0s
P10.26
Multi-step speed 12
-100.0–100.0%
0.0%
P10.27
Running time of 12
th
step
0.0–6553.5s (min)
0.0s
P10.28
Multi-step speed 13
-100.0–100.0%
0.0%
P10.29
Running time of 13
th
step
0.0–6553.5s (min)
0.0s
P10.30
Multi-step speed 14
-100.0–100.0%
0.0%
P10.31
Running time of 14
th
step
0.0–6553.5s (min)
0.0s
P10.32
Multi-step speed 15
-100.0–100.0%
0.0%
P10.33
Running time of 15
th
step
0.0–6553.5s (min)
0.0s
P10.34
Acceleration/decoration time
selection of 0–7 section of
simple PLC
0x0000–0XFFFF
0000
P10.35
Acceleration/decoration time
selection of 8–15 section of
simple PLC
0x0000–0XFFFF
0000
P17.27
Simple PLC and current steps
of multi-step speed
0–15
0
6.5.15 Graded multi-step speed reference
Graded reference is a speed reference method for hoisting applications. Graded reference supports
the graded operating lever mode and graded remote-control mode. Graded reference can implement
6-step speeds by combing the five graded multi-step reference terminals.
