INVT Goodrive350-19 Series User Manual

Goodrive350-19 series VFD Extension cards
-456-
The EC-IO501-00 extension card can be used in scenarios where the I/O interfaces of
Goodrive350-19 VFD cannot meet the application requirements. It can provide 4 digital inputs, 1
digital output, 1 analog input, 1 analog output, and two relay outputs. It is user-friendly, providing relay
outputs through European-type screw terminals and other inputs and outputs through spring
terminals.
EC-IO501-00 terminal function description
Category
Symbol
Name
Function
Power
PW
External power
supply
The working power of digital input is
provided by an external power supply.
Voltage range: 12–24 V
The terminals PW and +24V are shorted
before delivery.
Analog
input/output
AI3—GND
Analog input 1
1. Input range: 0–10 V, 0–20 mA
2. Input impedance: 20 kΩ for voltage input;
250 Ω for current input
3. Set it to be voltage or current input
through the corresponding function code.
4. Resolution: When 10 V corresponds to
50 Hz, the minimum resolution is 5 mV.
5. Deviation: ±0.5%; input of 5 V or 10 mA
or higher at the temperature of 25°C
AO2—GND
Analog output 1
1. Output range: 0–10 V, 0–20 mA
2. Whether it is voltage or current output
can be set through J5.
3. Deviation: ±0.5%; input of 5 V or 10 mA
or higher at the temperature of 25°C
Digital
input/output
S5—COM
Digital input 1
1. Internal impedance: 6.6 kΩ
2. Power input range: 12–30 V
3. Bidirectional input terminal
4. Max. input frequency: 1 kHz
S6—COM
Digital input 2
S7—COM
Digital input 3
S8—COM
Digital input 4
Y2—CME
Digital output
1. Switch capacity: 200 mA/30 V
