INVT Goodrive350-19 Series User Manual

Goodrive350-19 series VFD Extension cards
-468-
EC-PG502 terminals are described as follows:
Signal
Port
Terminal function
PE
Protective earth
terminal
Connected to the ground to enhance
anti-interference performance.
PWR
Encoder power
Voltage: 5 V ± 5%
Max. output current: 150 mA
GND
A1+
Encoder interface
1. Supporting Sin/Cos encoders
2. SINA/SINB/SINC/SIND 0.6–1.2Vpp; SINR
0.2–0.85Vpp
3. Max. frequency response of A/B signals: 200 kHz
Max. frequency response of C/D signals: 1 kHz
A1-
B1+
B1-
R1+
R1-
C1+
C1-
D1+
D1-
A2+
Pulse reference
1. Differential input of 5 V
2. Frequency response: 200 kHz
A2-
B2+
B2-
Z2+
Z2-
AO+
Frequency-divided
output
1. Differential output of 5 V
2. Supporting frequency division of 2
N
, which can be
set through P20.16 or P24.16; Max. output
AO-
BO+
