INVT Goodrive350-19 Series User Manual

Goodrive350-19 series VFD Commissioning
- 50 -
3. Set motor nameplate parameters in P02.
4. Set P90.00=4 to select the tower crane rotating function macro.
5. Perform low-speed trial running.
5.4.3 Macro parameters (P90.00=4)
Function
code
Name
Setting
Remarks
P00.01
Command running channel
1
Terminal
P00.06
Setting channel of A frequency
command
6
Multi-step speed running
P00.11
ACC time 1
10.0s
Low-frequency ACC time
P00.12
DEC time 1
18.0s
Low-frequency DEC time
P01.01
Starting frequency of direct
start
1.50Hz
P01.15
Stop speed
1.00Hz
P05.00
HDI input type
0x11
HDIA is digital input
HDIB is digital input
P05.03
Function of S3 terminal
16
Multi-step speed setting terminal 1
P05.04
Function of S4 terminal
17
Multi-step speed setting terminal 2
P05.05
Function of HDIA terminal
18
Multi-step speed setting terminal 3
P05.06
Function of HDIB terminal
7
Fault reset
P06.03
RO1 output selection
5
VFD fault
P06.04
RO2 output selection
9
Running in zero speed
P06.05
Output terminal polarity
selection
0X04
The polarity of RO1 is reversed.
P08.00
ACC time 2
15.0s
High-frequency ACC time
P08.01
DEC time 2
13.0s
High-frequency DEC time
P08.19
Switching frequency of
ACC/DEC time
16.00Hz
ACC/DEC time 2 is used when P08.19
is exceeded.
P10.04
Multi-step speed 1
16.0%
Corresponding to the max. frequency
P10.06
Multi-step speed 2
36.0%
Corresponding to the max. frequency
P10.08
Multi-step speed 3
60.0%
Corresponding to the max. frequency
P10.10
Multi-step speed 4
100.0%
Corresponding to the max. frequency
P25.01
Function of S5 terminal
6
Coasting to stop
P25.10
Extension card input terminal
polarity
0x01
The S5 terminal polarity is negative.
Note: The macro parameter table does not contain some parameters that are factory default
parameters.
