(8) The installation should ensure that the inverter is reliably grounded, and the material of
grounded metal conductor should be consistent with the metal material reserved for the
grounding of the inverter.
Do not remove any part and component of the inverter unintended; otherwise
damage to the device and physical injury may occur.
4.2.3 Connection cables
In order to regulate and compatible with the inverter AC/DC connector or terminal block
specifications, below requirements on the AC/DC leads connected to corresponding inverter
models should be fulfilled:
Table 4-4 Cable specifications
Min cross-section
area
mm²(length≤50m)
Min cross section
area mm²
(Length>50m)
Min cross section area
mm² (Length≤50m)
12kW / 15kW / 17kW
/ 20kW-M
30kW / 33kW / 35kW
/ 40kW
4.2.4 Miniature circuit breakers
In order to ensure safe operation of the inverter and circuits, it is recommended to configure
corresponding micro breaker or fuse on the DC input end and AC output end of the inverter. Table
4-5 is the requirements recommended for micro breaker:
Table 4-5 Breakers specifications
To Next Page
