INVT iMars User Manual

iMars grid-tied solar inverters Installation
21
No.
Name
Quantity
1
20kW / 25kW / 30kW / 33kW / 35kW / 40kW inverter
1
2
Installation bracket
1
3
Location hole template
1
4
operation manual
1
5
Communication connector
1
6
DC connector
6pairs /8 pairs
（35kW/40kW）
7
Expansion bolts M8*60
6
8
Hex combination bolt M8*20
6
9
Hex combination bolt M6*16
2
10
AC ring terminal
5
4.2 Before installation
4.2.1 Installation tools
Table 4-3 Tools list
No.
Installation tools
Instruction
1
Marking pen
Mark the installation hole
2
Electrodrill
Drill in the bracket or wall
3
Hammer
Hammer on the expansion bolts
4
Monkey wrench
Fix the installation bracket
5
Allen driver
Fasten the screws, remove and install AC wiring box
6
Straight screwdriver
For AC wiring
7
Megger
Measuring insulation performance and impedance
8
Multimeter
Check the circuit and AC and DC voltage
9
Electric iron
Weld communications cable
10
Wire crimper
Crimp DC terminals
11
Hydraulic clamp
Crimp ring terminal for AC wiring
4.2.2 Installation place
Select installation site according to below requirements:
(1) The height of the installation position should ensure that the line of sight is at the same
level as the LCD for viewing the parameters inverter conveniently.
