SPC Series Solar Pump Inverter Product overview
-6-
Field
Symbol
Description
Content
SPC
①
Product series
abbreviation
Abbreviation of solar pump controller
2K2
②
Rated power
The rated power is 2.2kW.
TR
③
Technical type
TR: 3PH
2
④
Output voltage class
2: 3PH 220V
4: 3PH 380V
6
⑤
Ingress protection (IP)
rating
0: IP00
6: IP65
H
⑥
Configuration frame
IP65 model type.
H: High performance
S: Standard
2.4 Product specifications
Model
SPC2K2TR20
SPC2K2TR26-S
SPC2K2TR26-H
SPC004TR40
SPC004TR46-S
SPC004TR46-H
SPC7K5TR40
SPC7K5TR46-S
SPC7K5TR46-H
Output power
(kW)
2.2
4
7.5
DC input
Max. DC input
voltage (V)
450
800
800
Start voltage (V)
120
250
250
Min. working
voltage (V)
70
200
200
Recommended
DC input voltage
range (V)
200–400
300–750
300–750
Recommended
MPP voltage (V)
330
580
580
AC output
Output voltage
(V)
0–230
0–400
0–400
Output
frequency (Hz)
0–400
0–400
0–400
Control performance
Control mode
V/F (SVPWM), SVC
Motor type
Asynchronous motor (AM) and synchronous motor (SM)
