SPC Series Solar Pump Inverter Dimension drawings
-60-
Appendix C Dimension drawings
C.1 External keypad structure
Keypad outline drawing
Keypad cut-out drawing (without
bracket)
You can mount the keypad on an external bracket, which is an optional part. The external
keypad can be up to 20 meters away from the inverter.
66.1
57.1
53.2
61.5
Keypad bracket Installation dimensions
76.1
87.1
82.5
