INVT XD3TL User Manual

Single Phase Hybrid Inverter Troubleshooting
63
No.
Fault Type
Fault
Code
Fault Description
Actions
and AFCI
8
Leakage
current error
10-01
High static leakage
current
1. If the fault occurs occasionally, it
may be caused by accidental abnormality
of external cables. You can restart the
inverter to resume normal operation.
2. If the fault occurs frequently or
lasts long, check whether the PV string is
grounded reliably.
10-02
Abrupt fault of
30mA
10-03
Abrupt fault of
60mA
10-04
Abrupt fault of
150mA
9
Relay failure
11-01
Open circuit of relay
Restart the inverter. If the fault still exists,
contact your dealer.
11-02
Short circuit of relay
10
Internal fan
failure
12-01
Internal fan failure
Restart the inverter. If the fault still exists,
contact your dealer.
11
DCI error
14-01
DCI error of
R-phase
Check whether the inverter and PV panel
are grounded reliably. Power off the
inverter for 5 minutes and then power it
on again. If the fault still exists, contact
your dealer.
12
Consistency
error
19-01
Inconsistent AC
voltage values
Restart the inverter. If the fault still exists,
contact your dealer.
19-02
Inconsistent BUS
voltage values
19-03
Inconsistent ISO
voltage values
19-04
Inconsistent PV
voltage values
19-05
Inconsistent GFCI
19-06
Bus voltage
sampling error
19-07
PV current sampling
error
13
AC voltage
error
31-01
One-level
under-voltage of AC
power
1. If the fault occurs occasionally, it may
be caused by momentary abnormality of
the power grid.
The inverter will resume normal operation
when the power grid gets back to normal.
2. If the fault occurs frequently, check
whether the power grid is connected
31-02
One level
over-voltage of AC
power
