Error Meaning
OSSD 2-3 CROSS
CHECK
Short-circuit error between MOS output 2 and 3
OSSD 2-4 CROSS
CHECK
Short-circuit error between MOS output 2 and 4
OSSD 3-4 CROSS
CHECK
Short-circuit error between MOS output 3 and 4
7.4.7 Flash errors (FLASH ERROR)
A flash error represents an error on the external flash.
7.4.8 Dynamic configuration error (DYNAMIC CONFIGURATION ERROR)
A dynamic configuration error indicates an invalid dynamic configuration ID.
7.4.9 Internal communication error (INTERNAL COMMUNICATION ERROR)
Indicates that there is an internal communication error.
7.4.10 Input redundancy error (INPUT REDUNDANCY ERROR)
Error Meaning
INPUT 1 Error in the redundancy on Input 1
INPUT 2 Error in the redundancy on Input 2
7.4.11 Fieldbus error (FIELDBUS ERROR)
At least, one of the inputs and outputs has been configured as “Fieldbus controlled”, but the fieldbus
communication is not established or not valid.
Error Meaning
NOTVALIDCOMMUNICATION Error on the Fieldbus
7.4.12 RAM error (RAM ERROR)
Error Meaning
INTEGRITY ERROR Wrong integrity check on the RAM
7.4.13 Sensor configuration errors (SENSOR CONFIGURATIONERROR)
Error occurred on the sensors during the configuration process or at the system power up. At least one of the
connected sensors did not get the correct configuration.
As details, the list of sensors not configured is reported.
7.5 ERRORevents (sensor)
7.5.1 Introduction
A diagnostic error is logged every time the periodic diagnostic functions detect a coming or going fault on the
LBK-S01 sensor.
7.5.2 Radar signal errors (Signal error)
Error Meaning
HEAD FAULT Radar not functioning
HEAD POWER OFF Radar off
MASKING Presence of object obstructing the field of view of the radar
7. Maintenance and troubleshooting
LBK System Series| Instruction manual v1.2 SET 2021|SAF-UM-LBKBus-en-v1.2|© 2020-2021 Inxpect SpA
83
