64
LBK System Series| Instruction manual v1.2 SET 2021 |SAF-UM-LBKBus-en-v1.2|© 2020-2021 Inxpect SpA
6. Installation and use procedures
6.1.4 Initiate LBK System Series
1. Calculate the position of the sensor (see "Sensor position" on page52) and the depth of the dangerous area
(see "Dangerous area calculation" on page54).
2. "Install the control unit" below.
3. Open the Inxpect Safety application.
4. Optional. "Synchronize the control units" below.
5. "Define the area to be monitored" below.
6. "Configure the inputs and outputs" below.
7. "Install sensors on the floor" on the next page or "Install the sensors on the machinery" on page66.
8. "Connect the control unit to the sensors" on page67.
Note: connect the sensors to the control unit off-site if access to the connectors becomes difficult once they
are installed.
9. "Save and print the configuration" on page68.
10. If available, "Set the control unit Ethernet parameters" on page68
11. "Validate the safety functions" on page68.
6.2 Install and configure LBK System Series
6.2.1 Install the control unit
WARNING! To prevent tampering, make sure the control unit is only accessible to authorized
personnel (e.g. key-locked electrical panel).
1. Mount the control unit on the DIN rail.
2. Make electrical connections, see "Terminal blocks and connector pin-outs" on page89 and "Electrical
connections" on page91.
NOTICE: if at least one input is connected, the SNS input "V+ (SNS)" and the GND input "V- (SNS)" must also
be connected.
NOTICE: when powered, the system takes about 2 s to start. During that period the outputs and the diagnostic
functions are deactivated and the green sensor status LEDs of the connected sensors flash.
Note: to correctly connect the digital inputs, see "Voltage and current limits for digital inputs" on page90.
6.2.2 Synchronize the control units
If there are more than one ISC-B01 control unit in the area, to configure the system and to perform the electrical
connections, see "Enable the multi-control unit synchronization function" on page48.
6.2.3 Define the area to be monitored
WARNING! LBK System Series is disabled during configuration. Prepare opportune safety measures
in the dangerous area protected by the system before configuring the system.
1. In the Inxpect Safety application, click Configuration.
2. Add the desired number of sensors in the plane.
3. Define the position and inclination of each sensor.
4. Define the angular coverage of the field of view for each sensor.
5. Define the selected safety working modes, the detection distance and the restart timeout for each detection
field of each sensor.
6.2.4 Configure the inputs and outputs
1. In the Inxpect Safety application, click Settings.
2. Click Digital Input-Output and define the input and output functions.
3. If the muting is managed, click Muting and assign the sensors to the groups according to the logic of the
digital inputs.
4. Click APPLY CHANGES to save the configuration.
