| Mount | Center-balanced Equatorial Mount (CEM) |
|---|
| Structure Material | All metal, CNC machined |
|---|
| Exterior finish | Anodized red/black |
|---|
| Level indicator | Level bubble |
|---|
| Dovetail saddle | 8" Losmandy D & Vixen |
|---|
| Hand Controller | Go2Nova® HC, 212, 000 objects database, star recognition |
|---|
| Cable management | Yes |
|---|
| Tripod | LiteRoc 1.75" Stainless Steel(7kg), optional tri-pier |
|---|
| Max payload* | 40 lb (18kg), exclude counterweight |
|---|
| Payload/Mount weight ratio | 2.28:1 |
|---|
| PEC | PPEC/Real time PEC |
|---|
| Tracking accuracy (PE)** | <±7.5 arcsec p-p (CEM40, CEM40G), or <0.3 arcsec RMS (CEM40EC) |
|---|
| Motor resolution | 0.08 arc seconds |
|---|
| Slew speed | 1×, 2×, 8×, 16×, 64×, 128×, 256×, 512×, MAX(~4.5°/sec) |
|---|
| Latitude adjustment range | 0°~ 60° (special CW shaft mounting if <10° ) |
|---|
| Azimuth adjustment range | ± 6° |
|---|
| Operation temperature | -10°C ~ +40°C |
|---|
| Right Ascension worm wheel | Φ110mm, 216 teeth aluminum |
|---|
| Declination worm wheel | Φ110mm, 216 teeth aluminum |
|---|
| Counterweight shaft | Φ28X280 mm, Stainless Steel (1.2 kg) |
|---|
| Counterweight | 11 lb (5 kg) X1 |
|---|
| Motor drive | Precision stepper motor, 1.8º/128X micro-step |
|---|
| Meridian treatment | Stop (0-14° pass), auto flip |
|---|
| Power consumption | 0.6A(Tracking), 0.9A(GOTO) |
|---|
| Power requirement | 12V DC 5A |
|---|
| AC adapter | 100V ~ 240V (included, indoor use only) |
|---|
| Polar Scope | Internal iPolarTM electronic polar scope |
|---|
| GPS | Yes |
|---|
| WIFI | External (optional) |
|---|
| Guiding scope/camera | Built in guiding scope and camera, iGuiderTM (CEM40G) |
|---|
| Autoguide port | ST-4 |
|---|
| Communication port | USB Port (on mount) |
|---|
| PC computer control | Yes (ASCOM) |
|---|
| Warranty | Two year limited |
|---|
