6 LIP-9000 Series User Guide - ST
1.4.1.2 Functions
Below gives a brief description of each control buttons or keys on the LIP-
Phone.
1. Ring/Message Indicator: Illuminates when ringing, or message waiting.
2. LCD Display: Phone interface for status, dialing directories, and text
message information.
3. Handset: Use to answer a call using the handset.
4. Speaker: Let you hear the caller’s voce in speakerphone mode.
5. Dial pad buttons: Use to dial a number, select a menu item, or input a
value.
6. Speakerphone button: Toggle the IP phone speakerphone On and Off.
And, it illuminates also when phone is in menu mode.
7. Volume control button: Use to adjust Ring, Headset, Handset, and
Speaker volume.
8. Flexible buttons: Assigns as Line or feature in Phone configuration.
LIP-9010 has 5-flexible buttons.
LIP-9020 has 10-flexible buttons.
LIP-9030 has 8-flexible buttons with maximum 3 pages.
LIP-9040 has 12-flexible buttons with maximum 3 pages.
9. Fixed buttons
Menu button: Accesses the menu for display and changes to the
IP Phone configuration.
Transfer (PGM) button: Transfers the current active call. And,
accesses the Program menu in idle state or it switches the dial pad
input mode in input screen. The dial pad mode displays in the
upper-right corner.
Directory button: Accesses the private or public directory.
Speed button: Assigns the speed number.
Message button: When the MWI LED indicates you have a
message use to access Voice Mail server.
DND (Do Not Disturb): Activates DND so that extension will not
ring. And it deletes a last letter in input screen.
