IPitomy IP290 - Phone Screen Display Features

www.ipitomy.com
IPitomy Communications
)
Hardware component instructions of the IP290 IP Phone are:
ITEM
DESCRIPTION
1
LCD Screen
Displays information about calls, messages, soft keys, time, date and
other relevant data:
• Call information — caller ID, call duration
• Icons (e.g.
• Missed calls or second incoming caller's information
•Time and date
2
Light Status
Red-Flashing: There is an incoming call.
Red-Steady: Off hook. or connecting call
3
Line Key
Green-Steady: On phone call
Red-Flashing: There is call coming in
Green-Flashing: The line is on hold
Dark: Accounts are idle
4
Soft Key
Labels automatically to identity their in-context-sensitive features
5
OK Key
Confirm action
6
Navigation Key
Scroll through the displayed information, and in the idle feature:
7
UP: Open the "All CONTACT LOG"
DOWN: Open the "MISSED CALL"
RIGHT: Open the "RECEIVED CALL"
LEFT: Open the "DAIL CALL"
C Key Cancels actions or rejects an incoming call, and these other
features: In the idle: Opens the "Phone Status".
Diagnosis: Press and hold 3 second to open "Hardware Diagnosis".
MUTE: "MUTE" feature is enabled if you press it while the conversation
making on the phone.
8
Functions Key
Conference\Redial\Transfer\Hold
9
Speaker Key
Toggles the hands-free speaker phone mode.
10
Keypad
Provides digits, letters and special characters in-context-sensitive
applications.
11
Headset Key
Toggles and indicates headset mode.
12
Message Key
Indicates and accesses voice messages.
13
Volume Key
Adjusts the volume of the handset, headset, speaker and ringer
3.2 Phone Screen Display Features
If the phone has successfully booted up, the idle LCD display will show information as below:
