M920 & M920W pH/Dual ORP Controller Owner’s Manual
E. ControllerPanelDescripons
1. Digital Displays and Func on LEDs
a. pH
1. Alert (High/Low) - red LED
2. Dose - green LED
3. Flashing Leds - Over Timer Alert
b. ORP
1. Alert (High/Low) - red LED
2. Dose 1 - yellow LED
3. Dose 2 - yellow LED
4. Flashing LEDs - Over Timer Alert
Figure 2: M920 Controller Components Connec ons
8
Electrical
Connec�ons
Flow Cell
Connec�ons
digital display
pushbutton
LEDs
Controller Communication
pH
pH
ORP
AC
Power
ORP2
ORP1
Flow
Switch
Temp
Sensor
Accessory
