14
Digital Intra-oral X-Ray Imaging System Pluto0001X /Pluto0002X User's Manual
Fig.2 Pluto0002X outline(unit: mm)
Item Detailed information
Pixel matrix 1500×1000 1800×1300
Pixel Pitch
Scintillation Screen CsI
Sensor size 38.5mm×25mm×5mm 40mm× 31mm×5mm
AD Conversion 16bits
Spatial resolution
Limited: 25lp/mm
Typical: >14.5lp/mm
Ingress Protection
IP68
(the highest point of enclosures with a height
greater than 1000mm below the surface of water,
and the duration of the test is more than 30
minutes)
Sensitivity >50lsb/uGy
Trigger sensitivity
Max linearity dose >400uGy
Length of cable <3m
interface Direct USB, USB2.0
Power
2.3 Timing and Electrical characteristics
Condition Min Type Max Unit
Integration time 0.05 4 s
Current consumption Image sensor head 30 50 mA
USB driver 200 350 mA
Readout time 1 1.5 s
