Digital Intra-oral X-Ray Imaging System Pluto0001X /Pluto0002X User's Manual
Software mode
2.4 AED trigger sensitivity
The AED trigger sensitivity should be matched with X-ray
source dose rate(correlated to power capacity) to achieve the
minimum X-Ray width, because the X-Ray during the AED
cycle time will not contribute to the image integration.
AED Trigger sensitivity
Level choose
AED cycle time(ms)
20 5.5
50 2.3
100 1.5
150 1.0
200 0.7
300 0.5
500 0.3
The x-ray machine used with intra-oral sensor in the current
is 60-70kV and 1-8mA. For different type of x-ray machine,
it is recommended to select the appropriate trigger threshold
according to the following tables:
kV mA SID
(mm)
Equivalent Skull size Min
Entrance
Dose
Rate(uGy/s)
Recommend
Trigger
Level(uGy/s)
Max
Entrance
Dose
Rate(uGy/s)
mA
(up to)
60 1 250 2mm Al 256 50 1000 4
8mm Al Standard 69
10mm Al Fat 51
