6: Appendices
Iridium Pilot User Manual 59
Environmental Specs
ADE (Above Deck Equipment) Enclosure Type RF-transparent dome-shaped
cover and metal base
Temperature Range -30 to +70 deg. Celsius
Relative Humidity 0 to 93% RH
Precipitation meets IPx6 (high pressure
water jets)
Wind in excess of 100 mph with proper
mounting (see Installation Guide)
BDE (Below Deck Equipment) Enclosure Type IP33 compliant (use inside
controlled environment)
Temperature Range 0 to +50 deg. Celsius
Physical Description
ADE Diameter 57.0 cm
Height 20.0 cm
Weight 12.5 kg
Mounting M10 bolts arranged in a 15 cm
diameter bolt circle
BDE Length 25.0 cm
Width 19.0 cm
Height 5.5 cm
Weight 1.35 kg
Mounting Indoor, at, vertical wall (supports
BDE weight)
Power Module Length 14.0 cm
Width 5.9 cm
Height 3.5 cm
Weight <0.5lb
Interconnect Cable Length (1) 45m
Length (2) 70m (optional)
