- Installation of the hose clamps
Installation of the articulation joint
- Be sure that the hoseclamps
are in the correct position. Leave 50 and
100 mm distance from the weld.
50
100
Self locking nut M12
Screw M12×35
leg assembly on main body
M16
M16×150
Symmetric trolley
Asymmetric trolley
Page 13
