Irrimec ST4 - Adjusting Travel Speed

The speed
7)7)
OPERATION
By-pass lever
Stop by-pass plate
Adjustment speed screw
Slow
Fast
- The trolley speed is variable and
several factors intervene:
- Flow - Pressure
- By-pass lever - Flap
- Pulleys - Gearbox
- Land
- The by-pass lever
- With an IRRIMEC hosereel:
- The flow minimum / maximum:
Turbine 10/50: from 10 to 50 m³/h
Turbine 25/130: from 25 to 130 m³/h
- The pressure minimum / maximum:
From 1 to 10 Bars
- The flap
Turbine pulley
Gearbox pulley
- Gearbox and pulley:
1°
7 - 19
25 - 69
4 - 19
25 - 69
5 - 23 7 - 38 13 - 64
16 - 83
27 - 135 45 - 224
40 - 112 67 - 187
7 - 32 10 - 53
40 - 112 75 - 187
11 - 32 19 - 53
2°
1°
2°
1°
2°
1°
2°
1°
2°
1°
2°
IRCO 600
B600
10/50
(900 to 2500 tr/mn)
25/130
(500 to 2500 tr/mn)
25/130
(500 to 2500 tr/mn)
10/50
(900 to 2500 tr/mn)
25/130
(500 to 2500 tr/mn)
25/130
(500 to 2500 tr/mn)
St4
St5
St6
St4
St5
St6
St7
St7
- WARNING: Before any adjustment, it is essential that PET tube isn’t in tension. (Fig.26)
Slowly remove tension on the drivebelt to allow hose drum to rest against
the anti return pawl.
- The speeds are calculated at the beginning of the coil
with a minimum spool diameter.
7 - 20
18 - 50
4 - 20
10 - 50
5 - 24
12 - 59
11 - 32
29 - 80
6 - 32
16 - 80
8 - 38
19 - 96
19 - 53
48 - 133
10 - 53
26 - 133
13 - 64
32 - 160
Page 25
Slow
Fast
- ATTENTION: The values reported in these tables are averages for a hose-reel with a standard
pulley. It is always possible to make modifications and variations on the diameter
of a pulley according to the needs of each customer.
