- Symmetric trolley for St4:
Attach the wheels to their axles
Slide the legs in and attach
them with the u-bolts.
- Automatic symmetric trolley for St4:
Attach the bar for automatic trolley lifting device
- Articulated asymmetric trolley for St5-6-7:
Assembly of the legs
M16
M16×120
installation of the rubber hose
Page 12
The trolleys
2)2)
b)b)
TRANSPORT
Assembly specifications
