ATTACHMENT
45
EN
428000467237 MILLENNIUM
USE AND MAINTENANCE MANUAL
6
WIRING DIAGRAM - 412100621000 - 2 of 2
B1
DEFROST VALVE
KM1 COMPRESSOR RELAY
C3 MULTIPOLAR TERMINAL BOARD S8 PRESSURE SWITCH
C5 ELECTRONIC CONTROL BOARD U1 COMPRESSOR
F2 FUSE U2 CONDENSER FAN
I1
SHOWCASE SWITCH
U3 EVAPORATOR FAN
I2 LIGHT SWITCH V1 FRONT HEATED GLASS
I3 ELECTRIC BOX SWITCH V2 SIDE HEATED GLASS
R3 PERIMETER TRIM HEATER T1 CONTROL UNIT TRANSFORMER
R4 PLANE TRIM HEATER T6 TRANSFORMER
R5 FRONT TRIM HEATER GD LED POWER SUPPLY
T7 TRANSFORMER HL LED LIGHT
S1
TEMPERATURE PROBE
D12 RECTIFIER BRIDGE
S2 DEFROST PROBE D13 RECTIFIER BRIDGE
BENCH MULTIPOLAR TERMINAL BOARD
1 ELECTRONIC CONTROL UNIT POWER SUPPLY PHASE INPUT
2 ELECTRONIC CONTROL UNIT POWER SUPPLY NEUTRAL INPUT
3 COMPRESSOR CONTROL PHASE OUTPUT
6 SOLENOID VALVE CONTROL PHASE OUTPUT
10 DEFROST VALVE POWER SUPPLY PHASE OUTPUT
12 LIGHTS POWER SUPPLY PHASE INPUT
13 LIGHTS POWER SUPPLY NEUTRAL INPUT
