428000467237 MILLENNIUM
USE AND MAINTENANCE MANUAL
9
WIRING DIAGRAM - 412100624000 - 2 of 2
BENCH MULTIPOLAR TERMINAL BOARD
1 ELECTRONIC CONTROL UNIT POWER SUPPLY PHASE INPUT
2 ELECTRONIC CONTROL UNIT POWER SUPPLY NEUTRAL INPUT
3 COMPRESSOR CONTROL PHASE OUTPUT
6 SOLENOID VALVE CONTROL PHASE OUTPUT
10 DEFROST VALVE POWER SUPPLY PHASE OUTPUT
12 LIGHTS POWER SUPPLY PHASE INPUT
13 LIGHTS POWER SUPPLY NEUTRAL INPUT
