ISDT Q8 Max - Product Specifications and Interface; Technical Specifications; Interface and Ports

Function Buttons
Model No: Q8 Max
Input voltage: DC 10~34V
Output voltage: DC 1~34V
Max. input current: 33A
Charging current: 0.2~30.0A
Discharging current: 0.2~3.0A
Max. charging power: 1000W
Max. discharging power: 30W
Balance current: 1.5A/Cell Max
Supported battery types and cell count:
LiFe,LiIon,LiPo 1~8S; LiHv 1~7S; Pb 1~12S; NiMH/Cd 1~16S
Product Specifications
Input BattGo: Support
Output BattGo: Support
Abnormal voltage alarm: Support
Incorrect cell count setting alarm: Support
Working temperature: 0℃~40℃
Storage temperature: -20℃~60℃
Dimension: 95×95×45mm
Weight: 290g
Power
Input
Display
Screen
Touch
Board
Micro USB
Update Port
Power
Output
Balance
Port
Fan
Vent
USB Port
