25
CHAPTER 4. NAME OF MAJOR COMPONENTS
SSM60-TM3240E4 / HE4
Fig.4-3
SRM48-TM3160E4
Fig.4-4
(1)
(2)
(3)
(4)
(5)
(6)
(7)
(8)
(9)
(10)
(11)
Mower deck
Gear box
Universal joint
Discharge cover
Belt cover (LH)
Belt cover (RH)
Belt
Pulley
Tension arm
Gauge wheel
Roller
(1)
(2)
(3)
(4)
(5)
(6)
(7)
(8)
(9)
(10)
(11)
Mower deck
Gear box
Universal joint
Discharge cover
Belt cover (LH)
Belt cover (RH)
Belt
Pulley
Tension arm
Gauge wheel
Roller
