OPERATION & SERVICE MANUAL FOR MOWER DECK
1) For TM3240, 3200, 3160 tractors
SSM48-TM3160E4
Fig.4-1
SSM54-TM3240E4 / HE4
Fig.4-2
CHAPTER 4. NAME OF MAJOR COMPONENTS
(1)
(2)
(3)
(4)
(5)
(6)
(7)
(8)
(9)
(10)
(11)
Mower deck
Gear box
Universal joint
Discharge cover
Belt cover (LH)
Belt cover (RH)
Belt
Pulley
Tension arm
Gauge wheel
Roller
(1)
(2)
(3)
(4)
(5)
(6)
(7)
(8)
(9)
(10)
(11)
Mower deck
Gear box
Universal joint
Discharge cover
Belt cover (LH)
Belt cover (RH)
Belt
Pulley
Tension arm
Gauge wheel
Roller
