52
OPERATION & SERVICE MANUAL FOR MOWER DECK
SSM48-TM3160E4
Fig.8-4
A: 138 - 140 mm (5.4 - 5.5 inch.)
B: 1 - 1.2 mm (0.04 - 0.05 inch)
SSM54-TM3240E4 / HE4
Fig.8-5
A: 136 - 138 mm (5.3 - 5.4 inch.)
B: 1 - 1.2 mm (0.04 - 0.05 inch)
SSM60-TM3240E4 / HE4
Fig.8-6
A: 136 - 138 mm (5.3 - 5.4 inch.)
B: 1 - 1.2 mm (0.04 - 0.05 inch)
SRM48-TM3160E4
Fig.8-7
A: 136 -138 mm (5.3 - 5.4 inch.)
B: 1 - 1.2 mm (0.04 - 0.05 inch)
