Ref. No.
1
2
3
4
5
6
7
8
9
Gear Oil: SAE40
Grease
Grease
Grease
Grease
Grease
Grease
Grease
Grease
60
OPERATION & SERVICE MANUAL FOR MOWER DECK
SMM54-TM3240E4 / HE4
Fig.9-5
Description Lubricant to be used Quantity
250 cc
Inject until grease overflow
Inject until grease overflow
Inject until grease overflow
Inject until grease overflow
Inject until grease overflow
Inject until grease overflow
As required
As required
Gear Box
Center Metal
Side Metal
Tension Arm
Fork / Arm
Gauge Wheel
Rear Link
Front Roller
Roller Pin
To Next Page
