ICP 3020 / ICP 4030 iMC-P Operating instruction
page 38
10 Accessories
Matching for each ICP 3020 / 4030 CNC machine, you can order the following accessories:
 clamping set (clamp lever SH1,SH2, 2 stop rails, hexagon socket wrench)
 additional mounting material for T-groove panel
 bench vise 1, 2
 additional collet chucks for working spindle
 tool kit cutter, driller, graver
 three different tool changer (linear, direct or round changer) with high frequency main
spindle drive, option: length measurement button
 rotation axis(axes)
 main spindle drive iSA 500, 750, 900
 working spindle UFM 500, UFM 1050
 vacuum clamping system isel-Vakufit
 pneumatics accessories
 cold air cooling isel-CoolMin: cooling unit with cold air nozzle (up to -20°C)
 exhaust unit
 spray-/cooling unit, cooling medium HL4
 work lighting
 CAD/CAM software isyCAD/CAM 2.5, Galaad/Lancelot, ProNC /6/
Information for compressed air connection of accessories:
To use the optional vacuum clamping system or the tool changer and collets
of the working spindle it’s necessary that the location of the machine has a
compressed air connection.
accessories
air pressure
air consumption
pneumatic vacuum pump
4 - 6 bar
100-150 l/min (1 nozzle)
cold air nozzle
3 - 10 bar
l/min
cover of the tool changer
3 - 6 bar
impulse
milling spindle with automatic tool change
> 7.5 bar
impulse
on the milling spindle mounted swivel unit for
exhaust (specially for woodworking)
2 bar
impulse
The necessary software for tool changing inclusive tool length measurement
is a part of the control- and programming software Remote / ProNC.
Look at all accessories for a professional installation and note the
applicable standards and safety regulations.
