User’s Manual WM3M4 &WM3M4C
Communication 4.4.1.1
The communication segment is intended for setting the serial communication parameters (RS485).
Figure 22: Display of device's communication settings in the MiQen software
Display 4.4.1.2
Backlight: is possible to turn on/off via serial communication.
Figure 23: Backlight window
Display params set the parameters displayed on the LCD.
Figure 24: Display params window
Custom text (list of available characters; see chapter 3.3.2)
Custom label (Table 3: LCD Custom string)
Cycling period defines the cycling period for measurements on LCD display, valid values from
5 s to 60 s.
Display MID info screen: displays FW identification screen and MID relevant counters on
LCD for a chosen period of time up to 60 seconds (see chapter Welcome screens and item
6.5.16).
