18-14

18. BF200D • BF225D • BF250D iST

TWIN ENGINE, TOP-MOUNT CONTROL

See page 18-35 for rigging diagram.

QTY

REQ.

PART NUMBER PART DESCRIPTION

1 06240-ZVL-701 Box Kit, R/C (Top/D) (Main)

( 1 ) 06323-ZVL-700 Panel Kit, Key Sw (Horizontal)

( 1 ) 06323-ZVL-710 Panel Kit, Key Sw (Vertical)

1 06324-ZVL-700 Panel Kit, S/S Sw (Twin)

1 06325-ZVL-000 Panel Kit, PTT Sw (Twin)

Optional ( 1 ) 06324-ZVL-000 Panel Kit, S/S Sw (All)

2 06653-ZZ3-730HE Cable Kit, Interface (10 ft)

1 06330-ZZ3-000AH NMEA Backbone Starter Kit

( 1 ) 32580-ZVL-600 Cable Assy, DBW Trunk (18 ft)

( 1 ) 32580-ZVL-700 Cable Assy, DBW Trunk (24 ft)

( 1 ) 32580-ZVL-800 Cable Assy, DBW Trunk (30 ft)

1 32540-ZVL-600 Cable Assy, Branch

( 2 ) 32590-ZVL-600 Cable Assy, Eng Drop (6 ft)

( 2 ) 32590-ZVL-700 Cable Assy, Eng Drop (10 ft)

( 2 ) 32590-ZVL-800 Cable Assy, Eng Drop (14 ft)

( 2 ) 06653-ZZ3-730HE Cable Kit, Interface (10 ft)

( 2 ) 06653-ZZ3-760HE Cable Kit, Interface (19.5 ft)

2 06177-ZX2-000HE 10 Micron "Spin-On" Fuel/Water Separator

V6D iST TM 2Eng1StaNMEAw-BB

Choose length

required

Choose length

required

Choose switch

orientation

Choose length

required
