IST 18.BF200D - Page 13

18-13
18. BF200D • BF225D • BF
250D iST
®
SINGLE ENGINE, TOP-MOUNT CONTROL, SECOND STATION, SMART KEY
See pages 18-33 and 18-47 for rigging diagrams.
QTY
REQ.
PART NUMBER PART DESCRIPTION
1 06240-ZVL-601 Box Kit, R/C (Top/S) (Main)
1 06250-ZVL-600 Box Kit, R/C (Top/S) (2nd)
( 1 ) 06311-ZVL-010 Unit Kit, Smart Key (Horizontal)
( 1 ) 06311-ZVL-801 Unit Kit, Smart Key (Vertical)
3 06653-ZZ3-730HE Cable Kit, Interface (10 ft)
1 06330-ZZ3-000AH NMEA Backbone Starter Kit
1 06328-ZZ3-760AH N2K Network Cable (15 ft)
( 1 ) 32590-ZVL-000
Cable Assy, Eng Drop (Single 6 ft) *
( 1 ) 32590-ZVL-810 Cable Assy, Eng Drop (Single 16 ft)
( 1 ) 32590-ZVL-820 Cable Assy, Eng Drop (Single 20 ft)
( 1 ) 32590-ZVL-830 Cable Assy, Eng Drop (Single 25 ft)
( 1 ) 32590-ZVL-840 Cable Assy, Eng Drop (Single 30 ft)
( 2 ) 32580-ZVL-600 Cable Assy, DBW Trunk (18 ft)
( 2 ) 32580-ZVL-700 Cable Assy, DBW Trunk (24 ft)
( 2 ) 32580-ZVL-800 Cable Assy, DBW Trunk (30 ft)
( 1 ) 06653-ZZ3-730HE Cable Kit, Interface (10 ft)
( 1 ) 06653-ZZ3-760HE Cable Kit, Interface (19.5 ft)
1 06177-ZX2-000HE 10 Micron "Spin-On" Fuel/Water Separator
* Requir
es Trunk Cable
V6D iST SK TM 1Eng2StaNMEAw BB
Choose length
required
Choose switch
orientation
Choose length
required
Choose length
required
